UAE United Arab Emirates customer visit C and Z purlin roll forming machine in our factory

UAE United Arab Emirates customer visit automatic C and Z purlin roll forming machine in our factory

Angle Light Keel Roll Forming Machine is used with T ceiling, usually used in hotels, railway stations, playgrounds, supermarkets, factories, car transport stations, interior decoration and other places set. It is PLC control, servo tracking cutting, has light weight, high strength advantages.

Specifications:

Raw material	PPGI, GI, Aluminum coils
Material thickness range	0.3-1mm
Forming speed	30-40m/min(without punching)
Rollers	12 rows
Material of forming rollers	45# steel with chromed
Shaft diameter and material	40mm, material is 40Cr
Controlling system	PLC
Material of cutting blade	Cr12 mould steel with quenched treatment
Voltage	380V/3Phase/50Hz or at your requirement
Main motor power	4KW
Hydraulic atation power	3KW
Way of driven	Gear box

Working process:

Decoiler - Feeding guide - Straightening - Main roll forming machine - PLC control system - Servo tracking cutting - Receiving table

Pictures of machine:

Training and Installation :
1. We offer installation service local in paid, reasonable charge.
2. QT test is welcome and professional.
3. manual and using guide is optional if no visiting and no installation.

Certification and after service:
1. Match the technology standard, ISO producing certification
2. CE certification
3. 12 months warranty since the delivery. Board.

Our advantage:
1. Short delivery period.
2. Effective communication
3. Interface customized.

Angle Keel Forming Machine

Angle Keel Forming Machine,Angle Keel Roll Forming Machine,Steel Angle Keel Roll Forming Machine,Angle Bar Roll Forming Machine
